P2.9 P3.9 P4.8 P5.2 Full HD LED TV Screens Die - Cast Aluminum Stage 2800cd

Name: P29 P39 P48 P52 Full HD LED TV Screens Die Cast Aluminum Stage 2800cd
Brand: Viso
Price: 1 USD

China P2.9 P3.9 P4.8 P5.2 Full HD LED TV Screens Die - Cast Aluminum Stage 2800cd wholesale

Brand Name : Viso

Model Number : PH4.81 PH5.95 PH.3.91

Certification : UL CE ROHS ISO ETL SGS SAA Fcc EMC

Place of Origin : China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA

Supply Ability : 8,000 square meters per month

Delivery Time : 4-6 work days

Packaging Details : Wooden box or Flight case

Brightness : ≥2200 Cd/㎡

Pixel Pitch : 1.6mm RCG

Led Chip : Nicha / Nationstar / Epistar / Cree / Osram

Refresh Frequency : ≥2880Hz

Cabinet Size : 500*1000mm

Dot Densit : 43264 Pixel/㎡

Tube Chip Color : Full Color Video RGB

Lifetime Typical Value (hrs) : 100,000

Working Voltage : AC 220V/110V ±10%

Contact Now

Led TV P2.9 P3.9 P4.8 P5.2 Fullcolor Rental Led Tv Screens Die - Cast Aluminum Stage 2800cd visoleddisplay

Features:

1. Vertical arrangement for LED chips, no color difference when looking from the left and the right;

2. Random dismantling, convenient maintenance;

3. Ghost-free image;

4. Signal and power double backup for module interfaces

Highlights:

1. Exclusive black matte technology for module masks improves the screen contrast a lot.

2. Vertical arrangement for LED chips (our patent) and in-diffusion design for lamp cups also improves the screen contrast.

3. ICs driven by constant current with pre-charge function can remove ghost image and make pictures clear without trailing.

4. Double backup for module signal interfaces can supplement another signal when pins of an interface break.

5. Double backup for module power interfaces can make the display not be affected when pins of input power break.

6. Modular structure design and convenient lock design make any cabinet be taken from any part of the screen easily.

7. Cabinets are die-casted with high-strength aluminum alloy, which makes cabinets enjoy light weight, strong bearing capacity and high outline precision.

Items	Parameter
Pixel Pitch	PH4.8mm	PH5.2mm	PH7.8125mm
Module Resolution(W*H)	104*208	96*192	64*128
Pixel Configuration	1R1G1B(in 3 n 1)
LED Encapsulation	Black SMD 2121	Black SMD 3528	Black SMD 3535
Pixel Density	43264 Pixel/㎡	36864Pixel/ ㎡	16384 Pixel/㎡
Driving Method	1/13 Scan	1/8Scan	1/4Scan
Refresh Frequency	≥2880Hz
Driver IC	Special constant current IC with high refresh rate & high grey scale
Grey Scale	14Bit
Cabinet Size	500*1000mm
White balance Brightness	900cd/ ㎡	1000cd/ ㎡	3500cd/ ㎡
Color Temperature	8000K±500 (customizable)
Viewing Angle	Horizontal 140° Vertical 120°
Optimal Viewing Distance	≥5m	≥5m	≥8m
Working Voltage	AC 220V/110V ±10%
Module voltage	DC4.2V
Max Power Consumption	250W/PCS	250W/PCS	350W/PCS
Avg. Power Consumption	125W/PCS	125W/PCS	180W/PCS
Lifetime	50000hours
Operating Temperature	–10℃ ～ 40℃
Net weight	12Kg/pcs	12Kg/pcs	12.2Kg/pcs
