Outdoor Full Color LED Screen Advertising , Double Sided IP67 LED Advertising Sign

Name: Outdoor Full Color LED Screen Advertising Double Sided IP67 LED Advertising Sign
Brand: Viso
Price: 1 USD

China Outdoor Full Color LED Screen Advertising , Double Sided IP67 LED Advertising Sign wholesale

Brand Name : Viso

Model Number : PH8

Certification : L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA

Place of Origin : China

MOQ : 1 Square Meter

Price : Negotiation

Payment Terms : L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA

Supply Ability : 6,000 square meters per month

Delivery Time : 4-5 work days

Packaging Details : Wooden box or Flight case

module size : 256mm×128mm / 320*160mm

pixel pitch : 8mm

pixel density : 15625dots / m2

Module resolution : 32dots(W)×16dots(H)

Pixel configuration : 1r1g1b

scan mode : 1 / 4

cabinet size : 768mm×768mm / 1920*1600mm

Interface : HUB75B

Power supply : 5V / 40A 5V / 60A

Contact Now

display screens for advertising Outdoor Full Color LED Display Advertising Double Sided screen IP67 led Sign

Products Function:

1. High intensity and can be adjusted , so can meet the request of teh customers according the application environment.

2. Best equality, commendably solve the problem of the mosaic, have the excellent consistency.

3. To pictures and character, have clear, exquisite and real display effect.

4. Big viewing angle to 110 degree at horizontal line, 60 degree at vertical line, you can see at every angle at thin range, no picture change, no color excursion.

5. Can repair each LED lamp. so the cost of maintain is lower and it is easier to be repaired.

Product Description


The specifications of modules

Items			Parameter
Product Model			P8 Full Color Led Module
Module size			256mm×128mm
Pixel pitch			8mm
Pixel density			15625dots / m2
Pixel configuration			RGB 3 in 1
Module resolution			32dots(W)×16dots(H)
Module maximum power consumption			25W
Module Thickness			2.8CM
Module Weight			0.55kg
Driving method			Constant Current Driving
Scanning method			1 / 4 scan
Interface			HUB75B
Brightness			≥7500cd / m2
The specifications of cabinets

Cabinet size			768mm x 768mm
Module quantity			18pcs
Power supply			5V / 40A 5V / 60A
Cabinet resolution			96×96dots
Optimal viewing distance			8M~50M
Optimal viewing angle			160°(W) 120°(H)
RHWorking temperature			(Work :-20°C~+50°C)
System operating humility			10%-95%
The specifications of power supplier

Operating Voltage			AC220V±10%
Average power consumption			300W / H
Maximum power consumption			≤600W / square meter
Electric current			≤20mA(single LED)
The specifications of control card
Control Panels			Pentium4 or above
Operating system			WIN98 / 2000/NT / XP
Control model			Synchronization with PC
The specifications of the main technical parameters

Driving device			Constant Current Driving
Refresh rate			≥600HZ
Grey scale			RGB Each 256, can display 16.7M colors)
MTBF			≥9000hours
Power switch			Automatic Switch
Display Mode			800×600 / 1024×768 / 1280×900

Application :

Billboard on the road . Bank info. Station . Stage .
